The FW562 is a Photoelectric duct smoke detector designed to provide early detection of smoke and/or the presence of combustion products in ventilation systems.
FW562-A/B/C are UL-listed devices according to UL 268A, and FW562C-A/B/C are ULC listed according to ULC-S529 for fire protection systems.
The FW562C detector operates at temperatures from 0ºC to 49ºC, can stand relative humidity levels of 0 to 93% and support 300 to 4000 ft/min of air velocity.
Equipped with a photoelectric smoke detector, the units will signal the presence of a dangerous amount of combustion product in the ventilation system.
Voltage Range: 17.6 to 28VDC
Compatible with Maple Armor Technologies’ control panel model FW106, FW106C, FW106S, FW106SC.
Operating Temperature: 32°F to 100°F (0°C to 38°C)
Operating Humidity: 0% to 93% RH
Mounting Location: Side and Top
